Custom High Pressure Hot Water Storage Tank / Stainless Steel
The products are designed and manufactured based on ASME VIII-1 code, meet the requirements of ASME, PED, AS1210 and oth
Send your inquiryDESCRIPTION
Basic Info.
Model NO. | C-10/6.55 |
Storage Medium | Moncombustible/Nontoxic |
Pressure Level | Medium Pressure (1.6MPa≤p<10.0MPa) |
Condition | New |
Material Spec. | 304 |
Test Pressure | 10.1MPa |
Design Pressure | 7.2MPa |
Installation Method | Vertical |
Corrosion Allowance | 0mm |
Transport Package | Iron Frame |
Specification | 10m³ |
Trademark | TK |
Origin | China |
HS Code | 73110090 |
Production Capacity | 20 |
Product Description
CODE:ASME SECT.VIII DIV.1 2021 EDITION |
Code Certification:ASME U |
Operating Pressure : 6.55MPa |
Design Pressure : 7.2MPa |
Temperature: 250ºC |
Minimum design metal temperature(MDMT) at MAWP:-20ºC at 7.2MPa |
Hydrostatic test pressure:10.1MPa at 0-48ºC |
Medium name:Water |
Corrosion allowance:0mm |
Gross volume:10m³ |
Empty weight:13481kg |
Zhejiang tank pressure vessel Co., Ltd. is a manufacturer specializing in the production of customized pressure vessels, we have ASME U and UM stamp authorization, and has obtained ISO9001-2015 quality system certification and PED Module H and Module H1 certificates issued by LRQA.
Standards or specifications that our products can comply with:
Product category | Design Code | Certifications |
Air Receiver | ASME VIII-1/GB150 | ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS |
Liquid Receiver | ASME VIII-1/GB150 | ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS |
Separator | ASME VIII-1/GB150 | ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS |
Adsorption Tank | ASME VIII-1/GB150 | ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS |
Heat Exchangers | ASME VIII-1/GB150/GB151 | ASME U/UM, PED Module H/H1/G/B+F, CRN, EAC, DOSH, MOM, AS1210,TS |
